MAXIMUM PROTECTION
Champion has dared mighty things to produce the Triumph Series. Until now maximum security has not been available in a safe of the Triumph’s class. Its heavy 10-gauge steel body with Steel Arch Doorway™ and Double-Steel Door Casement™ provides a pry-resistant fortress. The Triumph’s thick Delta Force™ door and precision cam-driven boltworks with 1½”-diameter door bolts provide maximum security. The Triumph’s state-of-the-art door defense systems include: full inner door steel, Four-Way Cam with Cam-Lock™, Diamond-Embedded Armor Plate™ lock protection, and a mechanical relocking system. Double fire seals assist with a 1650°F 90-minute fire rating—unsurpassed in its class. Add to this a velour interior, LED lighting, and a deluxe door organizer, and you complete the masterpiece.
BODY
• Classic Steel Arch Doorway™
• Two-Inch Thick Composite Walls
• 10-Gauge Steel Walls
• Three Layers of Fire Insulation
• Double-Steel Door Casement™
• Dual Fire Seals
MAXIMUM–SECURITY DOOR
• Exclusive Five-Inch Thick Delta Force™ Door
• 3/16″ Outer Door Steel, Full 12-Gauge Inner
• 3/4″ Reinforced Door Edge
• Three Layers of Fire Insulation
• Internal Ball-Bearing Hinges
• Five-Spoke Handle with Slip Clutch
BOLTWORKS
• Four-Way Active Boltworks
• Up to 20, 1½”-Diameter Door Bolts
• Bolt-Detent™ System
• Roughneck™ Bolt Guides
• Four-Way Cam with Cam-Lock™
LOCK PROTECTION
• Sargent & Greenleaf® Group II Dial Lock
• Champion’s Auto-Relock™ System
• Diamond-Embedded Armor Plate™
INTERIOR
• Plush Velour Interior
• High Capacity Gun Rack
• LED Lighting with Motion Sensor
• 110-Volt Power Receptacle
• Deluxe Door Organizer
RATINGS
• 1650°F 90-Minute Fire Rating
• Phoenix™ Class IV Fire Protection
• Tested in an ASME Certified Facility
• UL® Security Rating
• Lifetime Warranty
AVAILABLE COLORS
AVAILABLE SIZES
| SAFE MODEL | EXTERIOR DIMENSIONS | VOLUME (CUBIC FT.) | APPROX. WEIGHT (LBS.) | OUTER SHELL THICKNESS | OUTER DOOR THICKNESS | INNER DOOR THICKNESS | ACTIVE DOOR BOLTS | GUN CAPACITY | ||
| WIDTH | HEIGHT | DEPTH* | ||||||||
| TR-75 | 54" | 72.5" | 35.5" | 75 CF | 1705 | 10 ga. | 3/16" | 12 ga. | 20 - 1.5" | 102 |
| TR-60 | 48" | 72.5" | 30.5" | 56 CF | 1390 | 10 ga. | 3/16" | 12 ga. | 20 - 1.5" | 64 |
| TR-50 | 42" | 72.5" | 30.5" | 50 CF | 1275 | 10 ga. | 3/16" | 12 ga. | 18 - 1.5" | 58 |
| TR-40 | 36" | 66.5" | 28.5" | 38 CF | 1040 | 10 ga. | 3/16" | 12 ga. | 16 - 1.5" | 49 |
| TR-30 | 30" | 66.5" | 26.5" | 30 CF | 895 | 10 ga. | 3/16" | 12 ga. | 16 - 1.5" | 36 |
| TR-25 | 30" | 60.5" | 26.5" | 25 CF | 800 | 10 ga. | 3/16" | 12 ga. | 14 - 1.5" | 36 |
