NO COMPROMISE FOR GREATNESS
Built with the same exacting precision and superiority as Champion’s higher-end models, the Trophy Series offers rugged protection. Its 11-gauge steel body, reinforced with a Double-Steel Door Casement™, provides a solid steel foundation. Its thick Double Plate Steel Door™ with full inner door steel and numerous 1¼”-diameter four-way active door bolts provide excellent security. The Trophy’s door defense system includes: Champion’s Auto-Relock™ system and Diamond-Embedded Armor Plate™. To protect from the hottest fires, it boasts a 1500°F 75-minute fire rating. The Trophy Series comes in high-gloss and textured finishes, with a velour-covered interior and convenient door organizer.
BODY
• Up to Two-Inch Thick Composite Walls
• 11-Gauge Steel Walls
• Up to Three Layers of Fire Insulation
• Double-Steel Door Casement™
MAXIMUM–SECURITY DOOR
• Classic Steel Arch Doorway™
• 4½”-Thick Double Plate Steel Door™
• 10-Gauge Outer Steel, Full 14-Gauge Inner
• 3/4″ Reinforced Door Edge
• Internal Ball-Bearing Hinges
• Three Layers of Fire Insulation
• Five-Spoke Handle with Slip Clutch
BOLTWORKS
• Four-Way Active Boltworks
• Up to 16, 1-1/4”-Diameter Door Bolts
• Bolt-Detent™ System
• Roughneck™ Bolt Guides
LOCK PROTECTION
• Sargent & Greenleaf® Group II Dial Lock Standard
• Champion’s Auto-Relock™ System
• Diamond-Embedded Armor Plate™
INTERIOR
• Plush Velour Interior
• High Capacity Gun Racks
• LED Lighting with Motion Sensor
• 110-Volt Power Receptacle
• Steel Reinforced Top Shelves (TY-50, TY-40)
• Deluxe Door Organizer
RATINGS
• 1500°F 75-Minute Fire Rating
• Phoenix™ Class III Fire Protection
• Tested in an ASME Certified Facility
• UL® Security Rating
• Lifetime Warranty
AVAILABLE COLORS
AVAILABLE SIZES
SAFE MODEL | EXTERIOR DIMENSIONS | VOLUME (CUBIC FT.) | APPROX. WEIGHT (lbs.) | OUTER SHELL THICKNESS | OUTER DOOR THICKNESS | INNER DOOR THICKNESS | ACTIVE DOOR BOLTS | GUN CAPACITY | ||
WIDTH | HEIGHT | DEPTH* | ||||||||
TY-60 | 50" | 72" | 30.5" | 59 CF | 1220 | 11 ga. | 10 ga. | 14 ga. | 16 - 1.25" | 62 |
TY-50 | 42" | 72" | 30.5" | 49 CF | 1075 | 11 ga. | 10 ga. | 14 ga. | 16 - 1.25" | 52 |
TY-40 | 36" | 66" | 28.5" | 36 CF | 895 | 11 ga. | 10 ga. | 14 ga. | 14 - 1.25" | 42 |
TY-25 | 30" | 60" | 26.5" | 25 CF | 695 | 11 ga. | 10 ga. | 14 ga. | 14 - 1.25" | 24 |
TY-17 | 24" | 60" | 23.5" | 17 CF | 535 | 11 ga. | 10 ga. | 14 ga. | 12 - 1.25" | 12 |
